Exploring Kindle Paperwhite

Books

###How to start First, you need the latest firmware update firmware rev 5.4.4.2 and the KindleTool. Download booth of them, and extract the rootfs:

./kindletool extract update_kindle_5.4.4.2.bin

You’ll get the rootfs, the uImage kernel and some payload data.

###Exploring the rootfs:

HW and SW developed by lab126 in Cupertino, USA, assembled in China.

####Architecture codenames:

ADS
Mario
Nell
Turing
TuringWW
NellSL and NellWW
Luigi
Shasta
Yoshi

####Hardware:

Processor : ARMv7 Processor rev 5 (v7l)
BogoMIPS : 799.53
Features : swp half thumb fastmult vfp edsp neon vfpv3
CPU implementer : 0x41
CPU architecture: 7
CPU variant : 0x2
CPU part : 0xc08
CPU revision : 5
Hardware : Amazon.com MX50 YOSHIME Board
Revision : 50011
Serial : “B0241603xxxxxxxx”
BoardId : “00A16071xxxxxxxx”
RAM : 256 MB
WLAN : Atheros AR6003

####fstab:

# <file system>   <mount pt>    <type> <options>                                         <dump>  <pass>
/dev/mmcblk0p1    /             ext3   suid,exec,auto,nouser,async,rw,noatime,nodiratime 0      1
proc              /proc         proc   defaults                                          0      0
sysfs             /sys          sysfs  defaults                                          0      0
devpts            /dev/pts      devpts defaults,gid=5,mode=620                           0      0
usbfs             /proc/bus/usb usbfs  defaults                                          0      0
/dev/loop/0       /mnt/base-us  vfat   defaults,noatime,nodiratime,utf8,noexec,uid=0,gid=0,umask=0,shortname=mixed              0      0
/dev/mmcblk1p1    /mnt/base-mmc vfat   defaults,noatime,nodiratime,utf8,noexec,shortname=mixed              0      0
fsp#/mnt/base-us  /mnt/us       fuse   allow_other,umask=0,uid=0,gid=0,rw,max_write=65536,max_readahead=65536,noatime,noexec,nosuid,nodev,nonempty     0      0
fsp#/mnt/base-mmc /mnt/mmc      fuse   rw,max_write=65536,max_readahead=65536,noatime,exec,nosuid,nodev,nonempty     0      0

####Interesting binaries:

####dmesg through SSH with usbnet Linux version 2.6.31-rt11-lab126 (jenkins-official@sjc10-jbuild09) (collect2: ld returned 1 exit status) #1 Mon Apr 28 12:33:59 PDT 2014 CPU: ARMv7 Processor [412fc085] revision 5 (ARMv7), cr=10c53c7f CPU: VIPT nonaliasing data cache, VIPT nonaliasing instruction cache Machine: Amazon.com MX50 YOSHIME Board Board ID and Serial Number driver for Lab126 boards version 1.0 MX50 Board id - 00A16071xxxxxxxx Memory policy: ECC disabled, Data cache writeback On node 0 totalpages: 65536 free_area_init_node: node 0, pgdat c046e89c, node_mem_map c0498000 DMA zone: 192 pages used for memmap DMA zone: 0 pages reserved DMA zone: 24384 pages, LIFO batch:3 Normal zone: 320 pages used for memmap Normal zone: 40640 pages, LIFO batch:7 Built 1 zonelists in Zone order, mobility grouping on. Total pages: 65024 Kernel command line: consoleblank=0 rootwait ro ip=off root=/dev/mmcblk0p1 quiet eink=fslepdc video=mxcepdcfb:E60,bpp=8,x_mem=4M mem=256M user_debug=0x1 console=ttymxc0,115200 PID hash table entries: 1024 (order: 10, 4096 bytes) Dentry cache hash table entries: 32768 (order: 5, 131072 bytes) Inode-cache hash table entries: 16384 (order: 4, 65536 bytes) Memory: 256MB = 256MB total Memory: 255012KB available (3296K code, 359K data, 1004K init, 0K highmem) NR_IRQS:368 MXC IRQ initialized cko2_set_rate, new divider=0 MXC_Early serial console at MMIO 0x53fbc000 (options ‘115200’) console [ttymxc0] enabled Console: colour dummy device 80x30 Calibrating delay loop… 799.53 BogoMIPS (lpj=3997696) Mount-cache hash table entries: 512 CPU: Testing write buffer coherency: ok regulator: core version 0.5 NET: Registered protocol family 16 i.MX IRAM pool: 128 KB@0xd0840000 MX50 LPDDR2 MfgID: 0x1 [Samsung] CPU is i.MX50 Revision 1.1 MXC GPIO hardware Using SDMA I.API MXC DMA API initialized bio: create slab at 0 CSPI: mxc_spi-0 probed CSPI: mxc_spi-1 probed CSPI: mxc_spi-2 probed MXC I2C driver MXC I2C driver MXC I2C driver PMIC Light driver loading... mc13892 Rev 2.4 FinVer a detected Initializing regulators for mx50 yoshi. regulator: SW1: 600 <--> 1375 mV regulator: SW2: 900 <--> 1850 mV regulator: SW3: 900 <--> 1850 mV regulator: SW4: 1100 <--> 1850 mV regulator: SWBST: 0 mV regulator: VIOHI: 0 mV regulator: VPLL: 1050 <--> 1800 mV regulator: VDIG: 1200 mV regulator: VSD: 1800 <--> 3150 mV regulator: VUSB2: 2400 <--> 2775 mV regulator: VVIDEO: 2775 mV regulator: VAUDIO: 2300 <--> 3000 mV regulator: VCAM: 2500 <--> 3000 mV fast normal regulator: VGEN1: 3000 mV regulator: VGEN2: 1200 <--> 3150 mV regulator: VGEN3: 1800 mV regulator: VUSB: 0 mV regulator: GPO1: 0 mV regulator: GPO2: 0 mV regulator: GPO3: 0 mV regulator: GPO4: 0 mV PMIC ADC start probe PMIC Light successfully loaded Device spi3.0 probed NET: Registered protocol family 2 IP route cache hash table entries: 2048 (order: 1, 8192 bytes) TCP established hash table entries: 8192 (order: 4, 65536 bytes) TCP bind hash table entries: 8192 (order: 3, 32768 bytes) TCP: Hash tables configured (established 8192 bind 8192) TCP reno registered NET: Registered protocol family 1 LPMode driver module loaded Static Power Management for Freescale i.MX5 PM driver module loaded sdram autogating driver module loaded Bus freq driver module loaded mxc_dvfs_core_probe DVFS driver module loaded i.MXC CPU frequency driver squashfs: version 4.0 (2009/01/31) Phillip Lougher Registering unionfs 2.5.10 (for 2.6.31.14) msgmni has been set to 498 alg: No test for stdrng (krng) io scheduler noop registered io scheduler anticipatory registered io scheduler deadline registered io scheduler cfq registered (default) regulator: DISPLAY: 0 mV regulator: GVDD: 20000 mV regulator: GVEE: -22000 mV regulator: VCOM: 0 <--> 2749 mV regulator: VNEG: -15000 mV regulator: VPOS: 15000 mV regulator: TMST: 0 mV papyrus 1-0068: PMIC PAPYRUS for eInk display Amazon MX35 Yoshi Power Button Driver Serial: MXC Internal UART driver mxcintuart.0: ttymxc0 at MMIO 0x53fbc000 (irq = 31) is a Freescale MXC console handover: boot [ttymxc0] -> real [ttymxc0] mxcintuart.1: ttymxc1 at MMIO 0x53fc0000 (irq = 32) is a Freescale MXC mxcintuart.2: ttymxc2 at MMIO 0x5000c000 (irq = 33) is a Freescale MXC mxcintuart.3: ttymxc3 at MMIO 0x53ff0000 (irq = 13) is a Freescale MXC loop: module loaded mxc_rtc mxc_rtc.0: rtc core: registered mxc_rtc as rtc0 Probing mxc_rtc done mc13892 rtc probe start pmic_rtc pmic_rtc.1: rtc core: registered pmic_rtc as rtc1 mc13892 rtc probe succeed i2c /dev entries driver MXC WatchDog Driver 2.0 MXC Watchdog # 0 Timer: initial timeout 127 sec MXC Watchdog: Started 10000 millisecond watchdog refresh PMIC Character device: successfully loaded pmic_battery: probe of pmic_battery.1 failed with error -1 sdhci: Secure Digital Host Controller Interface driver sdhci: Copyright(c) Pierre Ossman mxsdhci: MXC Secure Digital Host Controller Interface driver mxsdhci: MXC SDHCI Controller Driver. mmc0: SDHCI detect irq 273 irq 2 INTERNAL DMA mxsdhci: MXC SDHCI Controller Driver. mmc1: SDHCI detect irq 0 irq 3 INTERNAL DMA Registered led device: pmic_ledsr Registered led device: pmic_ledsg Registered led device: pmic_ledsb nf_conntrack version 0.5.0 (4096 buckets, 16384 max) ip_tables: (C) 2000-2006 Netfilter Core Team TCP cubic registered NET: Registered protocol family 17 RPC: Registered udp transport module. RPC: Registered tcp transport module. kernel: I perf:kernel:kernel_loaded=0.48 seconds: VFP support v0.3: implementor 41 architecture 3 part 30 variant c rev 2 (...) mxc_rtc mxc_rtc.0: setting system clock to 2015-01-09 12:14:16 UTC (1420805656) Freeing init memory: 1004K (...) mmc0: new high speed SDIO card at address 0001 emmc: I def:mmcpartinfo:vendor=unknown, ddr=0, host=mmc1, manufacturer_id=254: mmc1: new high speed MMC card at address 0001 mmcblk0: mmc1:0001 MMC02G 1.83 GiB mmcblk0: p1 p2 p3 p4 INFO:Loaded module /lib/modules/eink_fb_waveform.ko (40028 bytes) mxc_epdc_fb_init_hw: 06_05_00ac_3c_2b4601_07_dc_00000dd8_85_12.wbf INFO:Loaded module /lib/modules/mxc_epdc_fb.ko default_panel_hw_init=1 default_update_mode=1 (51640 bytes) INFO:eink initialized... (786432 bytes) INFO:!!! Checking MBR /dev/mmcblk0 !!!! INFO:partition 2, start sector is 782336 INFO:partition 3, start sector is 913408 INFO:partition 4, start sector is 1044480 INFO:maximizing partition 2797568 sectors INFO:*** Partition table verified for /dev/mmcblk0 *** INFO:Setup loop device /dev/loop0 for /dev/mmcblk0p4 + 8192 INFO:Checking for updates... (auto-pilot mode) INFO:No update*.bin found; no update needed. INFO:no updates found. kjournald starting. Commit interval 5 seconds EXT3-fs: mounted filesystem with writeback data mode. ARC USB OTG/Gadget/Device Controller driver (26 Mar 2012) kernel: I perf:usb:usb_gadget_loaded=8.19 seconds: g_file_storage gadget: File-backed Storage Gadget, version: 7 August 2007 g_file_storage gadget: Number of LUNs=1 fsl-usb2-udc: bind to driver g_file_storage fuse init (API version 7.12) kjournald starting. Commit interval 5 seconds EXT3 FS on mmcblk0p3, internal journal EXT3-fs: mounted filesystem with writeback data mode. cypress reset cyttsp_bl_app_valid: App found; normal boot cyttsp: I mfgcmd :cmd_cmpl:: cyttsp_set_sysinfo_mode: hst_mode:0x90, mfg_stat:0x44, mfg_cmd:0x0 cyttsp_set_sysinfo_mode:SI2:tts_ver=0x15D5 app_id=0x2054 app_ver=0x020A c_id=0x000011 cyttsp_set_operational_mode: hstmode:0x0 tt_mode:0x0 tt_stat:0x0 cyttsp_power_on: Power state is ACTIVE input: cyttsp as /devices/platform/cyttsp.0/input/input0 cyttsp: I cyttsp_proc_write::command=unlock: Loading Atheros ar6003 driver SDIO: Enabling device mmc0:0001:1... SDIO: Enabled device mmc0:0001:1 kernel: I perf:wifi:wifi_driver_loaded=29.55 seconds: ar6003 Driver returning from ar6000_init_module ar6k_wlan mmc0:0001:1: firmware: requesting /opt/ar6k/target/AR6003/hw2.1.1/bin/active_calibration MAC from kernel xx:xx:xx:xx:xx:F0 ar6k_wlan mmc0:0001:1: firmware: requesting /opt/ar6k/target/AR6003/hw2.1.1/bin/otp.bin ar6k_wlan mmc0:0001:1: firmware: requesting /opt/ar6k/target/AR6003/hw2.1.1/bin/athwlan.bin ar6k_wlan mmc0:0001:1: firmware: requesting /opt/ar6k/target/AR6003/hw2.1.1/bin/data.patch.hw3_0.bin ar6003 driver: Completed loading the module ar6000_avail_ev mxc_rtc: saved=0x9f5778 boot=0x9f57af boot: I def:rbt:reset=user_reboot,version=232331: unregistered gadget driver 'g_file_storage' ARC USB OTG/Gadget/Device Controller driver unregistered ARC USB OTG/Gadget/Device Controller driver (26 Mar 2012) kernel: I perf:usb:usb_gadget_loaded=102.58 seconds: usb0: MAC ee:19:00:00:00:00 usb0: HOST MAC ee:49:00:00:00:00 g_ether gadget: Ethernet Gadget, version: Memorial Day 2008 g_ether gadget: g_ether ready fsl-usb2-udc: bind to driver g_ether [root@kindle root]# YAY!

###Virtualization: I was not able yet to start the kernel in QEMU, but i will update this post if i achieve something on this field.

###Opinion: lab126 made a nice work, but i would like to see a new e-book reader generation without X11, but with Wayland/MIR, with faster A4 HiDPI e-Paper panel and an SD-Card Slot. (Sandisk recently announced the world’s first SD card with a capacity of 512 gigabytes—half a terabyte of storage.) Oh, and with nice PDF rendering, please!
