March 03, 2026

ZFS replication using ZRepl

Secure storage

Till yesterday I used a simple USB disk as a ZFS backup pool. I had a moderately complex script started by cron at 6’o clok every morning to create a new snapshot about some vital information storing datasets and then zfs send and zfs recv it to the USB disk. It wasn’t too elegant and it made me always a bit nervous knowing how volitaile USB disks are. My 2 cents: do not use USB disks for ZFS, but If you have to, then at least sure you have some proper redundancy with non-USB disks.

Nevertheless, this was the past, because I have just set up a OmniOS VM in the cloud for backup purposes.

It was a real adventure as the service provider doesn’t allows to upload a custom iso via the admin webui, but you can request it and they attach the specified iso to the VM. After rebooting the VM the machine booted into the … err … something unknown anti-spam appliance. It seems they messed up something, but then finally my VM booted into OmniOS. After a quick setup my instance was ready to receive the backups. I have already heard about ZRepl before, but I haven’t had any real exposure so I have decided to give it a try. There is a OmniOS guide, which was a big motivation, but at the end of the day, I did a custom install, which could be interesting for you aswell:

First: you have to deciede:

which datasets needs to be backed up
which child-dataset should be excluded (if any)
how often should it backed up
how long should the backup stored
etc.

I got 20gigs of space on my VM, which is plenty, compared to the 8 gig USB drive I used so far.

To make my future life easier, I have created a file based zpool for easier migration. I got only one virtual disk, so I had no other choice. AFAIK: You shouldn’t store any sensitive date on rpool.

So I have followed the OmniOS ZRepl guide till the service configuration, but I have decided to go with ssh based authentication. This is not recommended, as this results in a lower bandwith, but this is also much easier to set up. Basically the client calls into the backup server and pushes their data via SSH. I only needed to set up some SSH keys and add them to the authorized_key on the VM side. Easy! (Comapred to rolling an own CA, for sure!) As input I have alsu used this blogpost

Lets see how I did it:

Backup Server:

root@omnibackup:~# cat /etc/opt/ooce/zrepl/zrepl.yml
# zrepl main configuration file.
# For documentation, refer to https://zrepl.github.io/
#
global:
  logging:
    - type: "stdout"
      level:  "debug"
      format: "human"

jobs:
- name: sink
  type: sink
  serve:
      type: stdinserver
      client_identities:
      - "client_nas"
  root_fs: "storage/zrepl/sink"
  recv:
    placeholder:
      encryption: off # See https://zrepl.github.io/configuration/sendrecvoptions.html#placeholders

Client:

root@omnios:~# cat /etc/opt/ooce/zrepl/zrepl.yml
global:
  logging:

    - type: "stdout"
      level:  "debug"
      format: "human"
jobs:
- name: client_to_master
  type: push
  connect:
    host: "test.extrowerk.com"
    identity_file: /root/.ssh/backup-id_rsa
    port: 22
    type: ssh+stdinserver
    user: root
  filesystems: {
    "tank/storage/vault": true,
  }
  send:
    encrypted: true
  snapshotting:
    type: periodic
    prefix: zrepl_
    interval: 10m
  pruning:
    keep_sender:
    - type: not_replicated
    - type: last_n
      count: 10
    keep_receiver:
    - type: grid
      grid: 1x1h(keep=all) | 24x1h | 30x1d | 6x30d
      regex: "^zrepl_"

I had to set up a new RSA based SSH key, add the public part to the backup-server authorized_keys file (for the root user!). I have tried to use Ed25519 based keys, but zrepl didn’t liked it for some reason. In the mantime I have created a PR at omnios-extra for the zrepl-0.7.0, hopefully the issue have been already fixed in this version.

There was also a question about the encrypted datasets. In this specific case I have decided to not-allow to the backup-VM to decrypt the data, so I had to add the following lines to the config:

  recv:
    placeholder:
    encryption: off

The zrepl user guide says: For encrypted-send-to-untrusted-receiver, the placeholder datasets need to be created with -o encryption=off. This doesn’t mean the data gets transferred or stored unencrypted.

After setting everything up I ‘ve got:

FILTER
┌────────────┐╔══════════════════════════════════════════════════════════════════════╗
│jobs        │║Job: client_to_master                                                 ║
│└──client_to│║Type: push                                                           ▒║
│            │║                                                                     ▒║
│            │║Replication:                                                         ▒║
│            │║   Attempt #1                                                        ▒║
│            │║   Status: done                                                      ▒║
│            │║   Last Run: 2026-03-03 21:02:50 +0100 CET (lasted 2s)               ▒║
│            │║     tank/storage/vault DONE (step 1/1, 1.6 KiB/624 B)               ▒║
│            │║                                                                     ▒║
│            │║Pruning Sender:                                                      ▒║
│            │║   Status: Done                                                      ▒║
│            │║   tank/storage/vault Completed  (destroy 1 of 11 snapshots)         ▒║
│            │║                                                                     ▒║
│            │║Pruning Receiver:                                                    ▒║
│            │║   Status: Done                                                      ▒║
│            │║   tank               skipped: filesystem is placeholder             ▒║
│            │║   tank/storage       skipped: filesystem is placeholder             ▒║
│            │║   tank/storage/vault Completed  (destroy 1 of 20 snapshots)         ▒║
│            │║                                                                     ▒║
└────────────┘╚══════════════════════════════════════════════════════════════════════╝
2026-03-03T21:09:00+01:00Q quit  <TAB> switch panes W wrap lines  Shift+M toggle nav

It seems the service runs just fine:

root@omnibackup:~# svcs -xv
root@omnibackup:~# zfs list -r -t snapshot storage
NAME                                                                         USED  AVAIL     REFER  MOUNTPOINT
storage/zrepl/sink/client_nas/tank/storage/vault@zrepl_20260303_062248_000     8K      -     99.8M  -
storage/zrepl/sink/client_nas/tank/storage/vault@zrepl_20260303_072248_000     8K      -     99.8M  -
storage/zrepl/sink/client_nas/tank/storage/vault@zrepl_20260303_082248_000     8K      -     99.8M  -
storage/zrepl/sink/client_nas/tank/storage/vault@zrepl_20260303_092248_000     8K      -     99.8M  -
storage/zrepl/sink/client_nas/tank/storage/vault@zrepl_20260303_102248_000     8K      -     99.8M  -
storage/zrepl/sink/client_nas/tank/storage/vault@zrepl_20260303_112248_000     8K      -     99.8M  -
storage/zrepl/sink/client_nas/tank/storage/vault@zrepl_20260303_122248_000     8K      -     99.8M  -
storage/zrepl/sink/client_nas/tank/storage/vault@zrepl_20260303_132248_000     8K      -     99.8M  -
storage/zrepl/sink/client_nas/tank/storage/vault@zrepl_20260303_142248_000     8K      -     99.8M  -
storage/zrepl/sink/client_nas/tank/storage/vault@zrepl_20260303_152248_000     8K      -     99.8M  -
storage/zrepl/sink/client_nas/tank/storage/vault@zrepl_20260303_162248_000     8K      -     99.8M  -
storage/zrepl/sink/client_nas/tank/storage/vault@zrepl_20260303_172248_000     8K      -     99.8M  -
storage/zrepl/sink/client_nas/tank/storage/vault@zrepl_20260303_182248_000     8K      -     99.8M  -
storage/zrepl/sink/client_nas/tank/storage/vault@zrepl_20260303_192248_000     8K      -     99.8M  -
storage/zrepl/sink/client_nas/tank/storage/vault@zrepl_20260303_200248_000     8K      -     99.8M  -
storage/zrepl/sink/client_nas/tank/storage/vault@zrepl_20260303_201248_000     8K      -     99.8M  -
storage/zrepl/sink/client_nas/tank/storage/vault@zrepl_20260303_202248_000     8K      -     99.8M  -
storage/zrepl/sink/client_nas/tank/storage/vault@zrepl_20260303_203248_000     8K      -     99.8M  -
storage/zrepl/sink/client_nas/tank/storage/vault@zrepl_20260303_204248_000     8K      -     99.8M  -
storage/zrepl/sink/client_nas/tank/storage/vault@zrepl_20260303_205248_000     0B      -     99.8M  -
root@omnibackup:~# Hi and thanks for reading my blog!
